XBC-3000
DC 24V 100A
System
| Operation system | Control system |
| PWM(Pulse Width Modulation) Control | DSP(Digital Signal Process) Control |
Rated capacity
| Rated output | DC 24V 100A |
Input part
| Input voltage | 3phase 380V |
| Input phase | 3phase 3wire |
| Input frequency | 50Hz |
| Input THD | Voltage less than 3% Current less than 5% |
| Control system | PWM Converter (element used : IGBT)) |
Battery part
| Battery type | Ni-CD(Nickel Cadmium) |
| Rated voltage | DC 24V |
| Number of cell | DC 24V – 1.2V 100AH 20Cells |
Output part
| Output voltage | DC 24V |
| Rated current | 100A |
| Equalizin charge | 31.0V(1.55V/Cell) |
| Floating charge | 28.4V(1.42V/Cell) |
| End of discharge | 22.0V(1.10V/Cell) |
| Output stability | Less than ±2% |
| Overall efficiency | 80% or more |
| Ripple | 2% RMS |
| Current limit | Current limitation at 110% overload |
| Overload capacity | 120% 5minutes |
| Audible noise | Less than 70dBA (at 1meter front) |
| SID secondary voltage stability | Less than ±8% |
Enclosure
| Finish color | Munsell No. 5Y 7/1 |
| Protection degree | IP21 |
| Material | SPHC, 3.2t, 2.3t |
